Thông tin chi tiết

• Frequency coverage                                  : 1.6–30 MHz (with 7 m; 23.0 feet or longer antenna element)

• Power supply requirement                      : 13.6 V DC (supplied from HF transceiver)

• Current drain                                              : Max. 2 A

• Operating temperature range                 : –30°C to +60°C (–22°F to +140°F)

• Weight                                                          : 2.5 kg; 5.5 lb

• Antenna connector                                    : SO-239 (50 W)

• Max. Input power                                        : 150 W (PEP)      100 W (continuous)

• Automatic tuning time                                : Approx. 2–3 sec. (general condition)  Max. 15 sec.

Approx. 1 sec. (re-tuning for a memorized frequency)

• Automatic tuning accuracy                         : SWR 2.0:1 (after tuning, except for multiples of 1⁄2 l)
